(Europe/US Ship) Lonsdor K518ISE K518 Key Programmer for All Makes with Odometer Adjustment No Token Limitation
Lonsdor K518ISE is an universal key programmer for all makes from Europe, America, Asia and China, also it can perform odometer adjustment for some makes. Lonsdor k518 Key Progrmmer are built-in Volkswagen 4th 5th adapter & RFID transponder reader / writer, program Toyota/Lexus smart key all key lost via OBD and free BMW FEM key programming (for all keys lost, enter 32-bit ISN code).
Lonsdor K518ISE Key Programmer with Odometer Correction for All Makes
Lonsdor K518ISE Key Programmer Highlights
1. Immobilization Key Programming
2. Odometer adjustment
3. Built-in Volkswagen 4th & 5th adapter
4. Built-in Chip & remote detection module.
5. Free BMW FEM key programming
6. No Need Token for all cars
Lonsdor K518ISE Package List:
1* Portable Bag(big)
1* Lonsdor K518ISE Main Host
1*Power Adaptor
1*USB Cable
1*Packing Bundle
1*OBD Test Cable
1*Extra Connector
1*User Manual
1*Portable Bag(small)
1*KPROG Adapter
1*RN-01 Board
1*E-01 Board
1*FS-01 Board
1*20P Cable
5*Backup Pin
1*Certificate
Lonsdor LKE Smart Key Emulator 5 in 1 needs to be purchased alone.
Lonsdor K518ISE Software Latest Update
Add 2018 2019 2020 Toyota 8A all keys lost programming
Add Ford Ranger, Expedition, Explorer, F150, F250, F250, F550 etc smart key till 2019br /> Unlock Toyota 8A H (OEM) smart key (unlock 1 key every day)
Add Nissan Teana (2019-) Smart Key Programming. All Key Lost. No Need PIN Code.
Add Subaru BRZ (2013-) 4D smart key all keys lost programming
Add Land rover Discovery 3 All Keys Lost via LKE smart key emulator generation.
Lonsdor K518ISE (K518 English Version) universal auto key programmer , with wider vehicle coverage in key programming, it is customized as the first masterpiece to the overseas market from Lonsdor. With months of preparation and rigorous testing, from the software design to the user experience, it is an epitomize of Lonsdor years of industry experience. It is tailored and perfect for vehicle locksmith, to help making their work easier, faster and more powerful!
Lonsdor K518 Key programmer Special Features:
Volvo (S40 S60 S80 V40 V60 V70 C30 C70 XC60 XC70 XC90) full version (mechanical key, smart key, keyless-go) key programmingToyota Lexus smart key all lost offline via OBD with 5-in-1 LKE emulator (94/ D4, 98, 39, 88/ A8, A9),
BMW CAS1 CAS2 CAS3 CAS3+ CAS3++ CAS4 CAS4+ FEM BDC key programming
Mitsubishi all key lost via simulate chip with emulator
Mazda latest model of smart key programming without PIN code
VW Audi Skoda Seat – MQB platform key programming & odometer adjustment
Porsche 911 / 997 / Boxster / Cayman (2005-2010) key programming via LKE emulator without PIN code
Hyundai KIA – 46 chip / 46 smart key / 47 smart key / 8A smart key / read PIN code
Peugeot Citroen DS – read PIN code & add key or all key lost for most of models
Renault Latitude / Fluence key programming without 32-bit PIN code
Renualt Koleos (2010-2016) read PIN code to program via OBD
GM series 2010-2018 – support more than 80% models via read PIN code from BCM
Subaru all key lost via OBD reset PEPS
Land Rover and Jaguar key programming via OBD – support FK72 / HPLA KVM version
Rolls-Royce Phantom key programming
Ferrari (458, F12, F149) – key programming via OBD
Jeep Grand Cherokee (2014-) – read PIN code to program
New Ssangyong series key programming without PIN code
Jeep Renegade (2017) key programming
Jeep Compass (2018) smart key programming
Maserati (2017) smart key programming----support Levante, Ghibli, Quattroporte
MG6 – read PIN code to program via OBD
Smart 453 – read PIN code to program
Generate dedicated key chip – 4D, 46, 48, T5, 7936
Key chip identification and remote frequency detection
Please check detailed K518ISE function and car list here
Europe:
Audi, BMW, Benz, VW, Volvo, Citroen, Ferrari, Maserati, Fiat, Lamborghini, Jaguar, MG,
Land Rover, Bentley, Lancia, Opel, Peugeot, Porsche, DS, Renault, Alfa Romeo, Smart,
Borgward
America:
Cadillac, Chevrolet, Dodge, GMC, Buick, Hummer, Ford, JEEP, Lincoln, Mercury
Asia:
Honda, Hyundai, Isuzu, KIA, Lexus, Mazda, Mitsubishi, Nissan, Ssangyong, Subaru, Suzuki,
Toyota, Shigaoka Queen
China:
Iveco, Trumpchi, BYD, Geely, Chery, Great Wall, Young Lotus (Basically all Chinese car
models are included)
Odometer Correction Car List:
VW, Porsche, Ford, Jaguar, Land Rover, Mazda, Audi, Renault, Hummer, Hyundai, Kia...
Note: more high-end cars will be updated very soon.
Lonsdor K518ISE Key Programmer with so many unprecedented features + built in RFID Transponder Reader / Writer
1st tool to introduce Kia / Hyundai Read PIN code function for Type 46 & 47 keys + Add Smart Key without PIN code;
1st tool to program keys for all Volvo models via OBD
1st tool to introduce Universal Smart Key Emulator shown picture below .
Toyota Smart Key all lost Lamborghini Porsche BMW & LandRover Ferrari Models covered + a whole lot of Chinese made vehicles Great Wall Haval Borgward MG Beiqi Foton as well
Lonsdor K518ISE Key Programmer Connection Diagram
Lonsdor K518ISE Key Programmer Technical Parameter:
RFID: Support 125KHz ASK,134.2KHz FSK
CPU: ARM Cortex-A7 Quad-core Processor Speed 1.34GHz
Display: 1024*600,7 inch IPS capacitive
Memory: eMMC 8G RAM 1G
Battery Capacity: 3800 mAh
Power Supply: DC12V 1A
Power port: 5.5x2.1mm
OBD Port: OBD-II
Comm Port: USB 2.0-type B
OBDII Protocols: ISO15765,ISO9141,ISO14230,SAEJ1850,VW TP1.6 TP2.0 etc
KPROG: Support programming MCU and EEPROM on ECU circuit board.
WIFI Communication Distance: 10m
K518ISE Key Programmer Main Unit Appearance:
1. Trademark: Lonsdor
2. Three-color indicator in turn will be: red - external power supply; blue - system power; yellow - communication status
3. Capacitive touch screen: display and touch operation function.
4. Switch: press and hold for 3s to start. When in start state, press and hold for 3s to restart or shutdown, for 10s to force to restart.
5. Volume: adjust volume size
6. Key frequency & chip recognition system: place the key on the surface to detect frequency, push the slot shell to the right, and put the key inside to detect chip
7. Setting: enter to set
8. Home: home page interface
9. Return: back to the previous step
10. Built-in antenna: antenna inside
11. Model: K518ISE
12. Screenshot: press the power button and volume down button together
Lonsdor K518ISE Key Programmer Main Interafce:
Lonsdor K518 ISE Key Programmer Setting interface:
KPROG adapter must be bound to K518ISE before using :
Step 1. Connect adapter to K518ISE with mainline
Step 2. Connect K518ISE with 12V power supply
Step 3. Enter into “Setting”
Step 4. Click “Bind adapter”
Step 5. Click “OK” to complete
Note: The KPROG adapter is specialized for part of Volvo car series and the new Maserati for the time being, more car models (like Jeep Grand Cherokee) is under developing, just check "One key update”for latest news.
Lonsdor K518ISE key programmer connecting the Kprog2 is able to read and write an eeprom soic chip/mcu chip. You can get data for backup or replacement.
Lonsdor KPROG-2 Adapter Read & Write EEPROM Chip List
| 24 series Support ATMEL & ST chip |
| AT24C01 128 byte |
| AT24C02 256 byte |
| AT24C04 512 byte |
| AT24C08 1K |
| AT24C16 2K |
| AT24C32 4K |
| AT24C64 8K |
| AT24C128 16K |
| AT24C256 32K |
| 93 series; Support ATMEL & ST chip |
| AT93C46-8bit 128 byte read/write |
| AT93C56-8bit 256 byte read/write |
| AT93C57-8bit 256 byte read/write |
| AT93C66-8bit 512 byte read/write |
| AT93C76-8bit 1024 byte read/write |
| AT93C86-8bit 2048 byte read/write |
| AT93C46-16bit 128 byte read/write |
| AT93C56-16bit 256 byte read/write |
| AT93C57-16bit 256 byte read/write |
| AT93C66-16bit 512 byte read/write |
| AT93C76-16bit 1024 byte read/write |
| AT93C86-16bit 2048 byte read/write |
| 25 series; Support ATMEL chip |
| AT25010 128 byte |
| AT25020 256 byte |
| AT25040 512 byte |
| AT25080 1K |
| AT25160 2K |
| AT25320 4K |
| AT25640 8K |
| AT25128 16K |
| AT25256 32K |
| AT25M01 1M |
| AT25M02 2M |
| 95 series; Support ST chip |
| 95010 128 byte |
| 95020 256 byte |
| 95040 512 byte |
| 95080 1K |
| 95160 2K |
| 95320 4K |
| 95640 8K |
| 95128 16K |
| 95256 32K |
| 95M01 1M |
| 95M02 2M |
| Weight | 3.500000 |
|---|
